DBT testing with DuckDB

1.1. Integrating it with DBT

To correctly parse DBT code (especially the templating part), we need to set it up properly. The easiest way is to create the .sqlfluff file in the repo root as follows:

.sqlfluff

[sqlfluff]
dialect = duckdb
templater = dbt
runaway_limit = 10
max_line_length = 100
indent_unit = space
exclude_rules = RF01, RF03, ST06, AL09
warnings = None

[sqlfluff:templater:dbt]
project_dir = ./dbt_src/
profiles_dir = ./.github/

Notice that we are using DuckDB as the dialect and that we need to set a couple of directories:

1. project_dir: with the root of the DBT project
2. profiles_dir: with the path where a DBT profile can be found (only for linting purposes).

And here is the very simple profile I use:

./dbt_src/profiles.yml

# This file is only used so that `pre-commit` can properly work
#   (for sqlfluff)

dbt_src:
  outputs:
    dev:
      type: duckdb
  target: dev

If needed, you can exclude some paths using the .sqlfluffignore file as mentioned in Sqlfluff Configuration

1.2. Automatic testing with pre-commit

With pre-commit, you can run the linter before each commit. More info about it in pre-commit.

To set up sqlfluff, you only need to add these lines to the .pre-commit-config.yaml file:

.pre-commit-config.yaml

repos:

# SQL linter
- repo: https://github.com/sqlfluff/sqlfluff
  rev: 3.0.6
  hooks:
  - id: sqlfluff-lint
    entry: sqlfluff lint --processes 0 --disable-progress-bar
    additional_dependencies: [ # Should match what we have in prod
      'dbt-duckdb==1.6.2',
      'sqlfluff-templater-dbt==3.0.6'
    ]
  - id: sqlfluff-fix
    entry: sqlfluff fix --show-lint-violations --processes 0 --disable-progress-bar
    additional_dependencies: [ # Should match what we have in prod
      'dbt-duckdb==1.6.2',
      'sqlfluff-templater-dbt==3.0.6'
    ]

Here we are using 2 jobs:

1. sqlfluff-lint: this gives better information about the failures.
2. sqlfluff-fix: this tries to fix the errors. It doesn’t always succeed.

3.1. Export CSVs

The simplest way of exporting data into duckdb is by a CSV file.

That file can later be imported with something like:

CREATE TABLE "{db}"."{table}"
AS SELECT *
FROM read_csv('{path}/{table}.csv', header=True)

See CSV - DuckDB for more information about read_csv.

3.2. Manual SQLs

There are some cases where the read_csv doesn’t work as expected. This has happened to me mostly when I have non-primitive types such as MAP, STRUCT, and/or JSON in one column.

To handle such cases, I define a sql file with:

1. Manual table creation
2. Manual inserts for some testing data

As an example, it would be something like this:

CREATE TABLE bronze__metadata.emr_history
(
    applicationId VARCHAR,
    jobRunId VARCHAR,
    name VARCHAR,
    createdAt TIMESTAMP,
    updatedAt TIMESTAMP,
    executionRole VARCHAR,
    state VARCHAR,
    stateDetails VARCHAR,
    totalResourceUtilization STRUCT(
        vCPUHour DECIMAL(10, 3),
        memoryGBHour DECIMAL(10, 3),
        storageGBHour DECIMAL(10, 3)
    ),
    networkConfiguration STRUCT(
        subnetIds VARCHAR[],
        securityGroupIds VARCHAR[]
    ),
    totalExecutionDurationSeconds BIGINT,
    executionTimeoutMinutes BIGINT,
    billedResourceUtilization STRUCT(
        vCPUHour DECIMAL(10, 3),
        memoryGBHour DECIMAL(10, 3),
        storageGBHour DECIMAL(10, 3)
    ),
    event_params MAP(
        VARCHAR,
        STRUCT(
            string_value VARCHAR,
            int_value BIGINT,
            double_value DOUBLE
        )
    ),
    p_extracted_at VARCHAR
);

INSERT INTO bronze__metadata.emr_history VALUES (
    '00fdi6bg3i758g0p', -- applicationId
    '00fginrueqgga00q', -- jobRunId
    'v7__crm.export-clone', -- name
    TIMESTAMP '2024-01-26 08:57:44.507', -- createdAt
    TIMESTAMP '2024-01-26 09:22:24.045', -- updatedAt
    'arn:aws:iam::634077897723:role/AmazonEMR-ExecutionRole-1685085488821', -- executionRole
    'SUCCESS', -- state
    NULL, -- stateDetails
    {
        'vCPUHour': 3.559,
        'memoryGBHour': 17.794,
        'storageGBHour': 17.794
    }, -- totalResourceUtilization
    {
        'subnetIds': ['subnet-0075f5bbf95862c10'],
        'securityGroupIds': ['sg-09ba4721cd92f7230']
    }, -- networkConfiguration
    1338, -- totalExecutionDurationSeconds
    360, -- executionTimeoutMinutes
    {
        'vCPUHour': 3.559,
        'memoryGBHour': 14.236,
        'storageGBHour': 0.0
    }, -- billedResourceUtilization
    MAP {
        'plataforma': {'string_value': 'landing', 'int_value': NULL, 'double_value': NULL},
        'subtipo_formulario': {'string_value': 'si', 'int_value': NULL, 'double_value': NULL}
    }, -- event_params
    '2024-01-31T13:00:39.571930' -- p_extracted_at
);

3.3. Generate testing data script

To export all that data, I use a script that:

1. Inspects everything in the testing_data folder
2. Loads all csv
3. Runs all sql files

The script is the following:

.github/scripts/create_duck_db.py

import os
import re
import shutil
import sys

import duckdb
from loguru import logger

PATH_DBT = "dbt_src"

DUCK_DB = f"{PATH_DBT}/awsdatacatalog.duckdb" # The name is for compatibility with Athena
PATH_DATA = "testing_data"

PROFILES_IN = "profiles/profiles.ci.yml"
PROFILES_OUT = f"{PATH_DBT}/profiles.yml"

IMPORT_STATEMENT = """
CREATE TABLE "{db}"."{table}"
AS SELECT *
FROM read_csv('{path}/{table}.csv', header=True)
"""


def remove_database_if_exists():
    if os.path.exists(DUCK_DB):
        logger.info(f"{DUCK_DB=} already exists, removing it")
        os.remove(DUCK_DB)


def get_databases_with_tables():
    logger.info("Reading local data to infer databases and tables to import")
    out_csv = {}
    out_sql = {}
    count_tables = 0

    for db in os.listdir(PATH_DATA):
        if "." in db:
            continue

        logger.info(f"Reading {db=}")
        csv = {}
        sql = {}
        for path, _, filenames in os.walk(f"{PATH_DATA}/{db}"):
            for filename in filenames:
                table, extension = filename.split(".")

                if extension == "csv":
                    csv[table] = path

                if extension == "sql":
                    with open(f"{path}/{filename}") as stream:
                        data = stream.read()

                    # Split queries and remove whitespaces
                    sql[f"{db}.{table}"] = [x.strip() for x in data.split(";") if x]

        logger.debug(f"There are {len(csv)} csv in {db=}")
        logger.debug(f"There are {len(sql)} sql in {db=}")
        out_csv[db] = csv
        out_sql[db] = sql
        count_tables += len(csv) + len(sql)

    count_dbs = len(set(out_csv).union(set(out_sql)))
    logger.success(f"{count_dbs} databases (with {count_tables} tables) where scanned")
    return out_csv, out_sql


def export_csv_tables(con, data):
    logger.info(f"Exporting all 'csv' tables in {DUCK_DB=}")

    for db, tables in data.items():
        if not tables:
            continue

        logger.info(f"Creating schema '{db}'")
        con.sql(f'CREATE SCHEMA "{db}"')

        logger.info(f"Creating all {len(tables)} tables in {db=}")
        for table, path in tables.items():
            logger.debug(f"* Creating table '{db}.{table}'")
            con.sql(IMPORT_STATEMENT.format(db=db, table=table, path=path))

    logger.success(f"All 'csv' tables exported to {DUCK_DB=}")


def export_sql_tables(con, data):
    logger.info(f"Exporting all 'sql' tables in {DUCK_DB=}")

    for db, tables in data.items():
        if not tables:
            continue

        logger.info(f"Creating all {len(tables)} tables in {db=}")

        for table, queries in tables.items():
            logger.debug(f"Running {len(queries)} queries for '{db}.{table}'")

            for query in queries:
                if not query:
                    continue

                query_preview = re.sub(" +", " ", query.replace("\n", " "))[:100]
                logger.debug(f"* Running query='{query_preview}...'")
                con.sql(query)

    logger.success(f"All 'sql' tables exported to {DUCK_DB=}")


def copy_profiles_file():
    if "win" in sys.platform:
        logger.warning(
            "Skipping copying 'profiles.yml' since you are on windows (not in a github action)"
        )

    else:
        logger.info(f"Copying '{PROFILES_IN}' to '{PROFILES_OUT}'")
        shutil.copy2(PROFILES_IN, PROFILES_OUT)


def main():
    remove_database_if_exists()
    data_csv, data_sql = get_databases_with_tables()

    with duckdb.connect(DUCK_DB) as con:
        export_csv_tables(con, data_csv)
        export_sql_tables(con, data_sql)

    copy_profiles_file()


if __name__ == "__main__":
    main()

4.1. In memory vs working with a file

dbt-duckdb can run in 2 ways:

1. With a duckdb file
2. In memory

Option 1 is the simplest given that we have a duckdb file with the testing data. With this option, each model run will be exported in the duckdb file. This is very useful when debugging since you can do manual queries to inspect the results and/or manually retry failed queries.

However, this way of working implies I/O operations which makes DBT run sequentially and not in parallel. To speed this up, we can run DBT in memory and attach a file for the testing data. This is what I recommend doing during CI.

Here is how you would declare both profiles:

dbt_northius:
  target: villoro_ci
  outputs:
    villoro_ci:
      type: duckdb
      path: ":memory:"
      attach:
        - path: awsdatacatalog.duckdb # The name is for compatibility with Athena
          alias: ""

    villoro_sequencial_ci:
      type: duckdb
      path: awsdatacatalog.duckdb # The name is for compatibility with Athena


    # Other profiles go here, such as PRE and PRO

4.3. Duckdb filename

You might wonder why the duckdb file is called awsdatacatalog.duckdb, and behind that name, there is a very interesting trick. In production, I’m using Athena (see Running DBT with AWS ECS (Fargate)) and there the default catalog is called awsdatacatalog. If you want to query the table athena_history inside the bronze__metadata schema you can either do:

SELECT * FROM bronze__metadata.athena_history
SELECT * FROM awsdatacatalog.bronze__metadata.athena_history

That allows us to define the DBT sources like:

sources:
  - name: nt_bronze__metadata
    database: awsdatacatalog # Needed for duckdb compatibility
    tags: ["metadata"]
    description: Raw metadata tables
    tables:
      - name: athena_history
      - name: dbt_execution
      - name: dbt_run_results
      - name: emr_history
      - name: raw_files

So queries using source(xx) will have the prefix awsdatacatalog and queries using ref(xx) will not have it. With duckdb, that implies that source(xx) will be read from the awsdatacatalog.duckdb file and ref(xx) will be run in memory.
