Scaling ECS Python Deployments with a Modular Monorepo

1.1 Single Workspace: Easy at First

In the initial phase of a project, having a single workspace is ideal:

• Just one pyproject.toml for all code
• One venv (via uv venv) to manage everything
• Easy to run tests, build, or deploy

This is the setup described in Fast and Reproducible Python Deployments on ECS with uv.

But as the codebase expands to include APIs, ML pipelines, or connectors, the single workspace model starts to break down—dependency conflicts emerge (e.g., prefect needing package_x<3 while pandas needs package_x>=4), and even simple jobs end up dragging massive venvs due to heavyweight libraries.

1.2 Multi-Workspace: Scales Better

When packages become logically independent (e.g. nt_sdk, nt_rds, nt_ml), a multi-workspace monorepo makes more sense:

• Each package has its own pyproject.toml
• Each has its own uv venv
• Each defines only what it needs (faster builds, smaller deploys)

src/
├─ nt_common/       # shared code (utils, schemas, etc.)
├─ nt_rds/          # jobs that interact with databases
├─ nt_api/          # API jobs
└─ nt_ml/           # ML jobs

In the next section, we’ll explain the benefits in more detail and how we organized the transition.

2.1 Creating Shared Code with nt_common

Sometimes, packages need to share common logic—models, helpers, utilities. That’s where nt_common comes in. It behaves like any other package but is added as a local dependency to others.

Steps:

1. Create src/nt_common/pyproject.toml and define your shared code in src/nt_common/nt_common/
2. From any other workspace (e.g., nt_api):

cd src/nt_api
uv add ../nt_common

This installs nt_common as a built wheel, with its pinned dependencies from its own uv.lock.

2.2 Minimal pyproject.toml example

Here’s a clean example for nt_api:

src/nt_api/pyproject.toml

[project]
name = "nt-api"
version = "0.1.0"
description = "Code for interacting with APIs"
readme = "README.md"
requires-python = ">=3.10, <3.13"
dependencies = [
    "nt-common",
]

[tool.setuptools.packages.find]
where = ["."]
include = ["nt_api*"]

[tool.uv.sources]
nt-common = { path = "../nt_common" }

[tool.setuptools.package-data]
nt_api = [
    "**/*.html",
    "**/*.j2",
    "**/*.yaml",
    "**/*.yml"
]

[dependency-groups]
dev = [
    "pytest>=9.0.0",
]

Key points:

• include explicitly declares which folder should be packaged
• package-data makes sure config files are bundled
• pytest under dev allows for easy testing without affecting prod dependencies

3.1. How It Works

We use pytest and importlib to:

• Recursively discover all .py files in the package
• Skip hidden directories and irrelevant content
• Try importing each module individually

This ensures the codebase reflects the dependencies declared in pyproject.toml, and any structural issues are caught early.

3.2. Minimal Test Code

src/nt_xxx/tests/test_imports.py

import importlib
from pathlib import Path
import pytest

PACKAGE_DIR = Path(__file__).resolve().parent.parent
PACKAGE_NAME = PACKAGE_DIR.name
CODE_DIR = PACKAGE_DIR / PACKAGE_NAME

def is_hidden_path(py_file: Path) -> bool:
    parts = py_file.relative_to(CODE_DIR).parts[:-1]  # exclude filename
    return any(part.startswith(".") for part in parts)

def iter_modules():
    for py_file in CODE_DIR.rglob("*.py"):
        if is_hidden_path(py_file):
            continue
        module_path = py_file.with_suffix("").relative_to(PACKAGE_DIR)
        yield ".".join(module_path.parts)

MODULES = list(iter_modules())

@pytest.mark.parametrize("module_name", MODULES)
def test_import_module(module_name):
    importlib.invalidate_caches()
    importlib.import_module(module_name)

This will be placed in each package and tested at each PR.

4.1 Matrix Setup for Pytest

We use a shared CI workflow that:

• Loops over each defined package (e.g., nt_common, nt_api, etc.)
• Sets up the virtual environment via uv sync
• Installs the project using uv pip install .
• Runs pytest inside the venv

Example:

.github/workflows/CI_pytest.yaml

description: CI_pytest
strategy:
  matrix:
    name:
      - nt_common
      - nt_api
      - nt_rds
      # Add new packages here

You can read more about this at Scalable GitHub Actions for Modern Repos.

4.2 Generic Dockerfile.venv

To build reproducible, isolated environments for each package, we use a shared Dockerfile.venv:

• Accepts --build-arg PACKAGE_NAME=nt_api and PACKAGE_VERSION=0.3.1
• Builds the venv using uv, copies the code, and installs the package non-editably
• Packages the virtual environment into a versioned .tar.gz

Example output:

nt_api__venv_0.3.1.tar.gz

Or optionally, structured by folder:

nt_api/venv_0.3.1.tar.gz

4.3 Uploading and Referencing Artifacts

Because each package produces its own archive, downstream systems (e.g., deployment scripts or S3 uploads) must:

• Handle versioned and namespaced paths
• Support prefix-based lookup

This makes it trivial to deploy or cache specific venvs for small jobs, without reusing bloated ML dependencies.

Ensure your upload_all.py or similar code respects the naming convention so each file is easy to find and consume.
