Solving the probem with small files in the Data Lake

5.1.1. Iceberg in Spark

According to the official documentation (Spark: Querying with SQL | Iceberg), you can query the files metadata with:

spark.sql(f"SELCT * FROM iceberg.{schema}.{table}.files")

With that in mind, you can create the export_table_stats function to be called every time you write a table:

import backoff
from prefect import get_run_logger

QUERY_STATS = """
SELECT
    '{schema}.{table}' AS table_name,
    count(*) AS total_files,
    sum(record_count) AS total_rows,
    round(sum(CAST(file_size_in_bytes AS DOUBLE)) / 1024 / 1024, 3) AS total_size_mb,
    CURRENT_TIMESTAMP AS exported_at
FROM iceberg.{schema}.{table}.files;
"""
TABLE_STATS = "iceberg.nt_bronze__metadata.raw_files"
ICEBERG_COMMIT_EXC = "org.apache.iceberg.exceptions.CommitFailedException"

class CommitFailedException(Exception):
    """Represents 'org.apache.iceberg.exceptions.CommitFailedException' exception"""

    pass

def log_error(details):
    logger = get_run_logger()

    msg = "'{target}' failed, backing off {wait:0.1f} seconds after {tries} tries"
    logger.warning(msg.format(**details))


@backoff.on_exception(
    backoff.expo, CommitFailedException, on_backoff=log_error, max_time=60 * 2  # 2 mins
)
def export_table_stats(spark, tablename):
    _, schema, table = tablename.split(".")

    query = QUERY_STATS.format(schema=schema, table=table)
    sdf = spark.sql(query)

    try:
        sdf.repartition(1).write.mode("append").format("parquet").saveAsTable(
            TABLE_STATS
        )

    # Catch the exception so that we can further inspect the type
    except Exception as exc:
        # If it's what we are looking for, raise our custom exception so that it can 'backoff'
        if ICEBERG_COMMIT_EXC == exc.java_exception.getClass().getName():
            raise CommitFailedException("Write failed (Commit Failed)")

        # If it's not the wanted exception, raise it
        raise exc

While Iceberg can handle concurrent write operations, issues can sometimes occur when exporting stats. Therefore, retries with Backoff are recommended. For more information, see Concurrent write operations | Iceberg.

5.1.2. Iceberg in Athena with DBT

You can query the files metadata with:

SELECT * FROM dbname."tablename$files"

For more info, read Querying Iceberg table metadata | Athena and Iceberg $files table | Trino.

To automate this, create the following macros:

macros/metadata.sql

{%- macro create_metadata_schema() -%}
    {%- if is_scheduled_pro_run() -%}
        {% do adapter.create_schema(api.Relation.create(database=target.database, schema=var("metadata")["db"])) %}
    {%- endif -%}
{%- endmacro -%}

{%- macro create_metadata_table_raw_files() -%}
    {%- if is_scheduled_pro_run() -%}
        CREATE TABLE IF NOT EXISTS {{ var("metadata")["db"] }}.{{ var("metadata")["tables"]["raw_files"] }} (
            table_name STRING,
            total_files BIGINT,
            total_rows BIGINT,
            total_size_mb DOUBLE,
            exported_at TIMESTAMP
        )
        LOCATION '{{ get_bronze_bucket() }}/metadata/{{ var("metadata")["tables"]["raw_files"] }}'
        TBLPROPERTIES (
            'table_type' ='ICEBERG',
            'format' = 'parquet',
            'write_compression' = 'snappy',
            'vacuum_max_snapshot_age_seconds' = '86400'
        );
    {%- endif -%}
{%- endmacro -%}

{% macro get_raw_files_table() %}
    {{ var("metadata")["db"] }}.{{ var("metadata")["tables"]["raw_files"] }}
{% endmacro %}

{%- macro export_metadata() -%}
    {%- if is_scheduled_pro_run() and (model.config.table_type == "iceberg") and (model.config.materialized != "view") -%}
        INSERT INTO {{ get_raw_files_table() }}
        SELECT
            '{{ this.schema }}.{{ this.table }}' AS table_name,
            count(*) AS total_files,
            sum(record_count) AS total_rows,
            round(sum(CAST(file_size_in_bytes AS DOUBLE)) / 1024 / 1024, 3) AS total_size_mb,
            CURRENT_TIMESTAMP AS exported_at
        FROM {{ this.schema }}."{{ this.table }}$files";
    {%- endif -%}
{%- endmacro -%}

{%- macro optimize_metadata_table() -%}
    {%- if is_scheduled_pro_run() -%}
        {{ optimize(get_raw_files_table()) }}
    {%- endif -%}
{%- endmacro -%}

{%- macro vacuum_metadata_table() -%}
    {%- if is_scheduled_pro_run() and var('vacuum_raw_files') -%}
        {{ vacuum(get_raw_files_table()) }}
    {%- endif -%}
{%- endmacro -%}

And their documentation:

macros/metadata.yml

version: 2

macros:
  - name: create_metadata_schema
    description: |
      Creates the schema 'metadata' when running in `Athena` and in **PRO** using `nt_pro` profile

  - name: create_metadata_table_raw_files
    description: |
      Creates the table 'raw_files' inside schema 'metadata'.
      This contains `iceberg` metadata about the files each table has.
      Will only be created when running in `Athena` and in **PRO** using `nt_pro` profile

  - name: export_metadata
    description: |
      Exports metadata about a specific table
      Will only be done when running in `Athena` and in **PRO** using `nt_pro` profile

  - name: get_raw_files_table
    description: Retrieves the fully qualified name of the raw files table from the metadata variables.

  - name: optimize_metadata_table
    description: Calls the `optimize` macro only when running in `Athena` and in **PRO** using `nt_pro` profile

  - name: vacuum_metadata_table
    description: |
      Calls the `vacuum` macro only when:

      * Running in `Athena`
      * Running in **PRO** using `nt_pro` profile
      * The variable `vacuum_raw_files` is `True` (happens when `--select` not present)

And then, declare the post-hook in the dbt_project.yml:

dbt_project.yml

models:
  your_project:
    +post-hook:
      - "{{ optimize() }}"
      - "{{ vacuum() }}"
      - "{{ export_metadata() }}" # <-- Add this

5.1.3. Track files_by_day

Now that we have a table with a snapshot of the metadata for each table whenever there is a write, we can create a table that tracks the latest state by day. This table will help us monitor partitioning problems.

Here is the DBT model for that:

models/files_by_day.sql

{{ config(unique_key='_uuid') }}

WITH source AS (
    SELECT *
    FROM {{ source('nt_bronze__metadata', 'raw_files') }}
),

fillna AS (
    SELECT
        table_name,
        total_files,
        exported_at,
        COALESCE(total_rows, 0) AS total_rows,
        COALESCE(total_size_mb, 0) AS total_size_mb
    FROM source
),

daily AS (
    SELECT
        table_name,
        CAST(exported_at AS date) AS export_date,
        {{ last('total_files') }}
            OVER (PARTITION BY table_name ORDER BY exported_at ASC) AS total_files,
        {{ last('total_rows') }}
            OVER (PARTITION BY table_name ORDER BY exported_at ASC) AS total_rows,
        {{ last('total_size_mb') }}
            OVER (PARTITION BY table_name ORDER BY exported_at ASC) AS total_size_mb,
        RANK()
            OVER (PARTITION BY table_name, CAST(exported_at AS date) ORDER BY exported_at ASC)
            AS _rank
    FROM fillna
),

daily_with_lags AS (
    SELECT
        table_name,
        export_date,
        total_files,
        total_rows,
        total_size_mb,
        LAG(total_files)
            OVER (PARTITION BY table_name ORDER BY export_date ASC) AS last_total_files,
        LAG(total_rows)
            OVER (PARTITION BY table_name ORDER BY export_date ASC) AS last_total_rows,
        LAG(total_size_mb)
            OVER (PARTITION BY table_name ORDER BY export_date ASC) AS last_total_size_mb
    FROM daily
    WHERE _rank = 1
),

daily_with_additions AS (
    SELECT
        ----------  ids
        {{ dbt_utils.generate_surrogate_key(['table_name', 'export_date']) }} AS _uuid,
        table_name,
        SUBSTRING(table_name FROM 1 FOR POSITION('.' IN table_name) - 1) AS schema_name,
        export_date,
        ----------  totals
        total_files,
        total_rows,
        total_size_mb,
        ----------  added datas
        COALESCE(total_files - last_total_files, total_files) AS added_files,
        COALESCE(total_rows - last_total_rows, total_rows) AS added_rows,
        ROUND(COALESCE(total_size_mb - last_total_size_mb, total_size_mb), 3) AS added_mb
    FROM daily_with_lags
)

SELECT *
FROM daily_with_additions

And the documentation for it:

models/files_by_day.yml

models:
  - name: files_by_day
    description: Shows total and added `files`, `rows` and `MBs` of each table
    columns:
      # ----------  ids
      - name: _uuid
        description: Unique identifier of the table. Composite key of `table_name` and `export_date`
        tests:
          - not_null
          - unique
      - name: table_name
        description: Full name of the table (format `schema.table`)
        tests: [not_null]
      - name: schema_name
        description: Name of the schema, extracted from `table_name`
      - name: export_date
        description: Day the statistics where exported for the given table
        tests: [not_null]

      # ----------  totals
      - name: total_files
        description: Total number of files the table has
        tests: [not_null]
      - name: total_rows
        description: Total number of rows the table has
        tests: [not_null]
      - name: total_size_mb
        description: Total size of the table in MBs
        tests: [not_null]

      # ----------  added
      - name: added_files
        description: Added number of files from the last write
        tests: [not_null]
      - name: added_rows
        description: Added rows from the last write
        tests: [not_null]
      - name: added_mb
        description: Increase in size (as `MB`) from the last write
        tests: [not_null]
